Calculate Molar Flow Rates Of Gases Before And After Reaction

Question

Benzene (C₆H₆) is converted to cyclohexane (C₆H₁₂) by direct reaction with H₂. The fresh feed to the process is 260 L/min of C₆H₆ plus 950 L/min of H₂ at 100°C and 150 kPa. The single pass conversion of H₂ in the reactor is 48% while the overall conversion of H₂ in the process is 75%. The recycle stream contains 90% H₂ and the remainder benzene (no cyclohexane). See Figure below.

(a) Determine molar flow rates of H₂, C₆H₆ and C₆H₁₂ in the exiting product.

(b) Determine the volumetric flow rates of the components in the product stream if it exits at 100 kPa and 200°C.

(c) Determine the molar flow rate of the recycle stream, and the volumetric flow rate if the recycle stream is at 100°C and 100 kPa.

Summary

The question belongs to Chemical Engineering and it discusses about calculation of molar flow rates of gases before and after reaction and volumetric flow rates of the components at high temperature.
